HW3410 Core i workstation
The HW3410 tower workstation is a high-performance computer equipped with 14th, 13th, and 12th generation Intel that supports LGA 1700 slots ® Core ™ The processor is equipped with high-speed DDR5 memory and integrates a range of top-level features and components, aiming to provide excellent computing power and unparalleled office experience. Its enhanced power supply design, high-quality heat dissipation solution, precise PCB design, and advanced network technology ensure stable operation under high loads, making it an ideal choice for professionals and creative workers.
Function Summary
Release the maximum computing power
Equipped with 14th/13th/12th generation Intel ® Core ™ Processor and Z790 chip
The HW3410 workstation, with unparalleled processing performance, can easily handle
The heaviest computing tasks ensure that every task is completed quickly and efficiently.
Fast storage experience
Supports up to 192GB DDR5 memory, equipped with multiple M.2 interfaces, with
Ensure high-speed data transmission and large capacity storage to ensure that every project can be streamed
Smooth operation and seamless switching.
High speed network connection
Built in 2.5Gbps LAN, supports optional Wi Fi 6E and Bluetooth 5.3, accurate
Ensuring ultra-low latency and stable high-speed network connectivity, helping the team achieve global success
Seamless collaboration within the perimeter.
Comprehensive expansion possible
Provide multiple PCIe slots and USB interfaces, supported by HW3410 workstation
Flexible hardware upgrades and customized configurations to meet diverse expansion needs
Please help you easily cope with future challenges.
Specifications
| Chipset | Intel ® Z790 chipset |
| Processor | Support Intel ® Core ™ 14th/13th/12th processors |
| Heat dissipation | Support air cooling/liquid cooling |
| Memory | Supports 4 DDR5 Non ECC memories with frequencies of 4800/5000/5200/5400/5600 MHz and a maximum capacity of 192GB |
| Storage |
Hard drive: Supports 4 M.2 hard drives, expandable 2 3.5-inch hard drives Interface: There are a total of 6 SATA 6Gb/s interface extensions onboard, 4 M.2 interfaces supporting 2242/2260/2280 specification storage devices |
| PCIe | Supports 1 PCIe 5.0 X16 slot, 1 PCIe 4.0 X16 slot, 1 PCIe 3.0 X16 slot, 1 PCIe 3.0 X1 slot |
| Network | Onboard Intel ® 2.5Gbps LAN， Support optional Intel ® Wi Fi 6E and Bluetooth 5.3 |
| Power supply | 750W/1250W/2000W/2050W/2600W Multiple power supply options |
| Port |
Front end: 2 USB 3.2 ports, 1 audio port, 1 3.5mm headphone jack Rear: 1 HDMI, 1 DP, 1 PS/2 interface, 6 Audio interfaces, 4 USB 2.0, 3 USB 3.2, 1 USB 3.2 Type-C |
| Operating system | Support Microsoft Windows Server and Linux operating systems (including mainstream distributions such as Ubuntu and CentOS) |
| Size | 442 x 250 x 518 mm (L*W*H） |
