HI5440 Tower Workstation
Through a split type liquid cooling pipeline
Designed to accurately cover the core heat sources of 4 high-performance graphics cards, combined with a high thermal conductivity cold plate, to achieve uniform temperature control of GPU temperature difference,
Ensure ultra quiet operation even under full load for a long time. Support four card parallel computing and lossless expansion. No matter what you pursue, it's enterprise
Whether it's industry level stability or ultimate performance, this workstation can ignite your passion in every moment!
Function Summary
Ultimate Core, Unleashing Passion
Supports 1 Xeon ® W-3400 series processor, multi-core simultaneous firing, capable of awakening. Each computing cycle is filled with infinite energy, helping you overcome the heaviest tasks.
Four card liquid cooling, with full computing power
Adopting a four card liquid cooling collaborative architecture, it effectively reduces temperature and ensures stable GPU output, presenting realistic visual and powerful computing effects for deep learning, 3D rendering, or VR applications.
Diversified storage, expandable at will
Supports 4 M.2 hard drive interfaces with expandable 8 3.5 "or 8 2.5 hard drive slots, multiple storage options for you to choose from, and fast data access that makes your heart beat faster.
High speed network, worry free connectivity
Equipped with 1 10GbE and 1 2.5GbE LAN port, balancing ultra-high bandwidth and multi scenario compatibility, ensuring both massive data transmission and stable connectivity
Specifications
| Chipset | Intel® W790 |
| Processor | Supports 1 Xeon ® W-3400 and Xeon ® W-2400 processor |
| Heat dissipation | liquid cooling |
| Memory | Supports 8 DIMM DDR5 6800 MHz RDIMM memory |
| Storage |
Hard drive: Supports 4 M.2 hard drives, expandable to 8 3.5 or 8 2.5-inch hard drives Interfaces: onboard 4 M.2 interfaces, 8 SATA 6Gb/s interfaces, 1 U.2 interface |
| PCIe | Supports 4 PCIe 5.0 x16 and 1 PCIe 4.0 x16 slots |
| Network | 1 10GbE LAN port, 1 2.5GbE LAN port |
| Power supply | Supports module power supplies such as 1650W/2050W/2600W |
| Port |
Front end: 2 USB 3.0 ports Rear: 5 USB 3.2 Type-A |
| Operating system | Support Microsoft Windows Server and Linux operating systems (including mainstream distributions such as Ubuntu and CentOS) |
| Size | 581 x 262 x 700mm(L*W*H) |
